SMALL SIZE SINGLE JERSEY CIRCULAR KNITTING MACHINE
Classification:
Single Jersey Circular Knitting Machine
Summary:
The company introduces international advanced technology and production inspection equipment. The development and design of products all adopt international advanced three-dimensional (3D) three-dimensional design.
Tel:
Tel:
- Presentation
- Specification
- Shipping
- Detail
- Equipment
- Features
- Fabric
-
- Commodity name: SMALL SIZE SINGLE JERSEY CIRCULAR KNITTING MACHINE
It adopts a four-track cam design of closed type with Draw-down cam, Tuck cam, Floating threads cam.
It adopts a four-track cam design of closed type with Draw-down cam, Tuck cam, Floating threads cam. The central total lift can easily and quickly adjust the weight of fabric; mouth feeding yarn with special design makes the increase of spandex with the facility. Use humanization design, additional feed yarn intermediate ring is easy observation and wearing yarn of operator, instead of touching the operator’s head of yarn; at the same time, making yarn delivery more fluid and smooth, to meet the requirements for high-speed weaving of machine. Sophisticate structural design makes needle cylinder more convenient to replace, through different triangular arrangements, a variety of tissue fabrics can be produced, such as mercerized cotton, polyester cover cotton, striped fabric, scouring pads, single and double Lacoste mesh fabric, elastic couth, scale loop +spandex, cotton spandex single jersey, etc. Products are used to vest, T-shirt, sportswear, aerobic suit, and swimming suit.
One machine has lots of functions, and a single-surface machine can be converted into a sweater machine or towel machine just by changing key parts; -
Diameter：8″-30″
Gauge：15G -44G
Feeder：24F -408F
Speed：16-60r/min
Power：2HP -11.5HP -
-
Condition: New Product Type:fabric Type:Circular Production Capacity:250-750kg Place of Origin: Fujian China
(Mainland)Brand Name:HANMA
(circular knitting machine)Model Number:HM-DF4
(circular knitting machine)Power(W):5.5kw
(circular knitting machine)Knitting Style: knitted Knitting Method: Single Computerized: Yes Weight:2.5TON Dimension(L*W*H):2.35*2.28*2.28M After-sales Service Provided:Engineers
available to service machinery overseasspeed:0-30RPM Certificate: CE machine type: single jersey turn way: anticlockwise fabric function:sports garment
-
No Description Supplier Brand Quantity 1 Insert flake type cylinder &dial(Germany metal) Hanma China 1 unit 2 Needles Groz-beckert Germany 1 set 3 Sinkers Kern liebers Germany 1 set 4 Positive storage yarn feeders Neo Hanma China 1 unit 5 Oiling lubricator Hanma China 1 unit 6 Yarn creel Hanma China 1 set 7 One ways Take-down device Yong tai Taiwan 1 set 8 Invertors for motor controller Sunyue Taiwan 1 set 9 fabric Spreader equipment Hanma China 1 set 10 cam Hanma China 1 set 11 Control panel Hanma China 1 set 12 Automatic dust fans with blower equipment. San song China 1 set 13 Radar type round 360”Clear dust equipment San song China 1 set 14 Motor Hanma Taiwan 1 set 15 Spare tools 1 set 16 Operation manual for invertors & controller panel 1 set 17 Extra Spare parts : (a) 100pcs needles (b)100pcs sinkers
(c)Feeders 1pcs (d)Air blower gun 1 set (e)Fuse 4pcs
(f) Yarn carrier 1pcs (g)Needle oil 1 liter -
