- Commodity name: DOUBLE JERSEY JACQUARD CIRCULAR KNITTING MACHINE
The double jersey electronic jacquard circular knitting machine features a computerized actuator to select needles on the cylinder.
The double jersey electronic jacquard circular knitting machine features a computerized actuator to select needles on the cylinder. Any complicated structure/design of fabric can be input into the special control system by computer, which can knit various designs of jacquard fabric. Professionally-designed high-speed CAM system makes needles less likely to be broken. The bed plate is made of steel ball-bearing runway structure with oil immersion, guaranteeing stable running of the machine, low noise and high abrasion resistance.
Area of application
· Sport- and leisurewear
· Technical textiles
· Home Textiles
Stitch structure
· Elastane plating
· Elektronic-Jacquard
· Eyelet stitch pattern
Knitting technique
· Elektronic-Jacquard -
Diameter 30”-38“ Gauge 12G-24G Feeder 54F-84F Speed 12-18r/min Power 5.5HP Equipment Groz-beckert NEEDLES; Tatung Motor; Plz mail me for further info Color Blue/Grey/According to your requirement Packing Wooden Cartoon Gross Weight 2.8t Net Weight 2.5t Q’ty/20GP/40GP 3sets/20GP,6sets/40GP Lead time 45days after getting deposit Loading port Xiamen Port Payment terms T/T,L/C at sight MOQ 1set -
-
Condition: New Product Type:fabric Type:Circular Production Capacity:250-750kg Place of Origin: Fujian China
(Mainland)Brand Name:HANMA
(circular knitting machine)Model Number:HM-DF4
(circular knitting machine)Power(W):5.5kw
(circular knitting machine)Knitting Style: knitted Knitting Method: Double Computerized: Yes Weight:2.5TON Dimension(L*W*H):2.35*2.28*2.28M After-sales Service Provided:Engineers
available to service machinery overseasspeed:0-30RPM Certificate: CE machine type: Double jacquard turn way: anticlockwise fabric function:sports garment The double jersey electronic jacquard circular knitting machine features a computerized actuator to needles on the cylinder.
☛ Able to knit various designs of jacquard fabric
☛ Features a computerized actuator to needles on cylinder
☛ Application Area: Clothing,sheet, pillow towel, fabrics for children and other home textiles. -
No Description Supplier Brand Quantity 1 Insert flake type cylinde&dlar(Germany metal) Hanma China 1 unit 2 Needles Groz-beckert Germany 1 Set 3 Electric Positive storage yarn feeders LGL Italy 1 Unit 4 Oiling lubricator Hongsheng China 1 Set 5 Yarn Creel Hanma China 1 Set 6 One way Take-up device. Yongtai China 1 Set 7 Invertor Sunyue China 1 Set 8 Fabric Spreader equipment Hanma China 1 Set 9 Sinker Cams Japan 1 Set 10 Knit cams Japan 11 Digital indicator control panel Hanma China 1 set 12 Computer system Chuangda China 1unit 13 Needle selector system Chuangda China 1 unit 14 Automatic dust fans with blower equipment. San song China 1 set 15 Radar type round 360’ clear dust equipment San song China 1 set 16 Spare tools 1 set 17 Operation manual for invertor & controller panel 1 set 18 Extra Spare parts : (a) 100pcs needles (b)100pcs sinkers
(c)Feeders 2pcs (d)Air blower gun 1 set (e)Fuse 4pcs
(f) Yarn carrier 1pcs (g)Needle oil 1 liter(h) extra needle selector 1 pc -
Product Name:
Jacquard Fabric Brand:
Funfurlala Size(width):
52inch Materials:Style:Technics:
Polyester / rayonWovenJacquard Features:
modern Design Weight:
179 / gsm MOQ:
1 meters Package:Logo and Color:
Roll packingCustomized Accepted OEM Service:
Welcome Colour Fastness:
3-4 degree
